设备型号/Model |
LC450UTD |
LC450GTD |
LC450PUTD |
LC450PGTD |
LC450PITD |
|
激光类型/Laser type |
UV纳秒UVnanosecond |
Green纳秒/Greennnoscand |
UV皮秒/UVpicosecond |
Green皮秒/Greenpicosecond |
红外皮秒 Intraredpicosaand |
|
激光波长/Laser wavelength |
355nm |
532nm |
355nm |
532nm |
1064nm |
|
激光功率/Laser power |
15W/20W/25W |
40W/60W/70W |
15W/30W/40W |
30W/60W/80W |
20W/30W/50W |
|
激光冷却方式/Laser cooling mode |
水冷/water-cooling |
|
|||
|
激光点径/Laser spot diameter |
20 m |
30 m |
20 m |
30 m |
30 m |
|
激光等级/Laser level |
Class4 |
||||
|
激光照射范围/Laser Cooling Mode |
300*400mm |
||||
|
激光可变焦/Laser Zoom |
自动Z轴(选配自动对焦)/Automatic z-axis(0ptional autofocus) |
||||
|
设备类型/Platform Type |
双平台/Dual platform |
||||
|
工作方式/Working mod |
X振镜移动，Y平台移动X galvanometer moving,Y platform moving |
||||
|
基本规格/Basic specification |
|||||
|
重复定位精度/Repeated positioning accuracy |
±3μm |
||||
|
切割精度/Cutting accuracy |
±30μm |
||||
|
加工效果/Machining effect |
热影响≤40μm/Heat effect≤40 m |
||||
|
加工图案/Processing pattern |
直线、斜线、曲线、异形等/Straight line,oblique line,curve,special shape,etc |
||||
|
基板厚度/Substrate thickness |
≤2mm |
||||
|
切割最小线宽/Cut minimu4m line width |
30um |
40um |
30um |
40um |
50um |
|
软件/software |
|||||
|
软件界面/Software interface |
中英文双界面，操作便捷，三级管理菜单/Chinese and English dual interface,convenient operation,three-level management menu |
||||
|
视觉/vision |
mark点定位，视觉巡边/Mark points to the target,visual edge finding |
||||
|
数据来源/Data source |
DXF |
||||
|
系统连接功能/System connection function |
可连接SHOPFLOW,MES,IMS,PMS,等管理系统/It can connect to SHOPFLOW.MES.IMS.PMS and other management systems |
||||
|
其他/other |
|||||
|
输入电压/Input voltage |
AC220V 50/60HZ |
||||
|
气压源/Pressure source |
≥0.5MPa |
||||
|
环境要求/Environmental requirement |
5-40°,30-80Rh |
||||
|
设备功率/Equipment power |
2KW |
||||
|
设备尺寸(长*宽*高mm)Equipment size (L*W*Hmm) |
1000*1695*1605mm(L/W/H) |
||||
|
设备重量/Equipment weight |
1200kg |
||||
|
远心透镜照射范围/Exposure range of the telecentrics lens |
50*50mm |
||||
|
开机预热时间/Boot preheating time |
3min |
||||
